Electrophoresis Varnish Rectification Device
summary
The company has absorbed the international advanced electrophoretic
paint rectifier device technology, and developed its own new
equipment.
This machine uses special resin imported from Japan, suitable for
soluble series anode electrophoresis paint film.
Our device fully meets the requirements of imported related
equipment, and is a necessary equipment for aluminum anodized
electrophoresis.
Working principle:
With the continuation of electrophoresis in the production, the
impurity ions of the electrophoresis tank will increase due to the
introduction of the pretreatment process or the impurity ions of
the section itself, thus changing the conductivity and PH value of
the electrophoresis. In order to effectively remove the harmful
impurities in the electrophoresis tank, such as sulfate ion and
other impurity ions, the electrophoretic paint rectification
equipment should be used.
The principle is to use ion exchange resin to remove impurity ions,
so as to control the PH value and conductivity of the storage tank.
So that the foundation is within the allowable process parameters.
When the resin is saturated with the impurity ions in the tank, the
resin will lose its effect and must be regenerated.
The regeneration process is the opposite to the refining process,
using hydrogen ions or hydroxide ions to regenerate and exchange
the impurity ions attached to the ion exchange resin.
Basic configuration:
- Mitsubishi Japanese kation resin(WK-40) :150L
- Mitsubishi Japanese anion resin(SA-10AP) :450L
- Stainless steel delivery pump:1 unit
- Kation tower Ø 600 X 1600mm H: 1 unit
- Anion tower Ø 800 X 1800mm H :1 unit
- Electrical control device: 1 unit
- Pneumatic control device: 1 set
- Stainless steel supporting rack :1 unit
- Pipe line and valve, jet gun, flow gauge, pressure gauge:1 set
